Are you tired of voltage uncertainties? Look no further, because the Lonely Binary DC Voltage Sensor is here to save the day! With our brand-new module, you can confidently measure and monitor voltage levels with ease.
Experience the wonders of our resistive divider principle design. By reducing the interface terminal input voltage by 5 times, we ensure optimal compatibility with Arduino analog inputs. Say goodbye to voltage worries and hello to accurate measurements!
But that's not all. Our voltage detection module has some serious power limits. It can handle input voltages up to a whopping 25V (for 5V systems) or 16.5V (for 3.3V systems). That's enough voltage to make even the bravest electrons tremble in fear!
Thanks to the impressive resolution of our analog module (0.00489V to be exact), you'll never miss a voltage beat. The AVR chips in our module work their magic, providing precise measurements with every reading. We're all about that accuracy, baby!
And get this: our voltage detection module can detect the tiniest voltage signals. We're talking about a minimum detectable input voltage of a mere 0.02445V. It's like having a microscope for your voltage measurements!
So why settle for uncertainty when you can trust Lonely Binary? With our DC Voltage Sensor, you'll be the master of your voltage domain. Say goodbye to voltage confusion and hello to precise measurements. Don't wait any longer—join the Lonely Binary revolution today!
|Voltage input range||DC0-25V|
|Voltage detection range||DC0.02445V-25V|
|Voltage simulation resolution||0.00489V|
|DC input interface||positive terminal connected to VCC, negative terminal connected to GND|
|Output interface||"+" connected to 5/3.3V, "-" connected to GND, and "s" connected to AD pin|
|Net Weight||2.5 g|
|Dimension||(L) 26 mm x (W) 13 mm x (H) 11 mm|
What’s in the Box
There are 6 pieces in the retail box.
The listing price is for
- 1 x 25V Voltage Sensor Module
